Kayo

KAYO AU150 CVT

®

£1,899.00 incl. VAT

Colour
Bank transfer · Pay on collection

Technical Specification

Age
Wheel Size
9/9
Weight
155kg
Max Rider
Charging Time
Range
Motor
4 stroke, SOHC, air cooled
Battery
Ref: AU150CVT
Product Description

The AU150 CVT ATV is a remarkably capable mini utility quad from the manufacturers of Stomp Pit Bikes (Kayo). Perfect for small holdings or where a full size ATV is simply too big & expensive to run. Kayo undertook 4 years of development in some of the harshest conditions an ATV will ever face, determined to produce a quad bike that would outperform anything in its class.

They succeeded and the result is an ATV that plenty of bottom end grunt, is light, nimble, has amazing crawling & climbing ability, rugged looks and a price that will make your jaw drop. The utility quad has plenty of load space & a detuned 150 cc YX race engine for lugging stuff around Forget about what you think you know about quads, Kayo just re-wrote the rule book. Suitable for riders of 10 years and over. 3 speed manual 150 cc 4-stroke, 1 speed reverse, 3 hydraulic disk brakes, and double wishbone suspension with adjustable pre load. Front & Rear carry racks with wrap-around plastics to keep you dry.

Key Features

Engine Displacement
149.6cc
Transmission
CVT with R-N-F
Wheel Size
9/9
Seat Height
740mm
Dry Weight
155kg
Manufacturer and model
Manufacturer: KAYO; Distributor: Stomp Distribution LTD; Model: AU150 CVT ATV
Engine
Engine: 4 stroke, SOHC, air cooled; Engine Displacement: 149.6cc; Compression Ratio: 10.3:1
Ignition and starting
Ignition System: CDI; Starting System: Electric
Motor and power
Max Power: 5.8kw @ 7500 RPM; Max Torque: 8.3Nm @ 6000rpm
Suspension
Front Suspension: 270mm Non-Adjustable; Rear Suspension: 280mm Non-Adjustable
Wheels
Wheel Size: 9/9
Tyres
Front Tyres: 10×9; Rear Tyres: 10×9
Brakes
Front Brake: Hydraulic disc; Rear Brake: Hydraulic disc
Warranty
12 months, parts only
Vehicle Size
1690 x 975 x 1010mm
Wheelbase
1080mm
Ground Clearance
140mm
Seat Height
740mm
Dry Weight
155kg
Bore x Stroke
57.4 x 57.8mm
Fuel Capacity
5.5 litres
Transmission
CVT with R-N-F
Measurement
Value
Seat Height
740mm
Wheelbase
1080mm
Wheel Size
9/9
Vehicle Size
1690 x 975 x 1010mm
Ground Clearance
140mm
Contact us by appointment if you need help checking suitability and fit.
