Kayo

KAYO TT140

®

£1,299.00 incl. VAT

Colour
Bank transfer · Pay on collection

Technical Specification

Age
Wheel Size
17/14
Weight
73.0kg
Max Rider
Charging Time
Range
Motor
YX140, 4-Stroke, Oil Cooled
Battery
Ref: TT140
Product Description

The legendary YX140 cc (the engine that defined a generation) forms the basis of this insanely well-considered pit bike which is most definitely not just for kids.

Kayo is hands down the largest manufacturer of pit bikes in the world today, dwarfing Honda with massive volume and the hi-tech robot welding lines to match the demand of their bikes.

The TT140 takes advantage of the gigantic leaps Kayo has taken in the industry over the past 20 years.

Precision welding, the best available components suppliers, insane attention to detail and robustness to match the Japanese manufacturers.

The TT140 features a stainless exhaust system, thumping YX140 4-stroke engine, massive rear travel with matching USD forks and a twin spar cradle frame to tie it all together.

There is nothing else on the market that’s this well considered and that’s even before you cast your eyes across the jaw dropping plastics and graphics designs.

Whether you are a hardened field racer ready to do battle with your friends or kitted-up ready for a blast around the track hitting some gnarly jumps, the TT140 has you covered for many years to come.

Key Features

Engine Displacement
140cc
Transmission
Manual four speed with N-1-2-3-4
Wheel Size
17/14
Seat Height
855mm
Dry Weight
73.0kg
Manufacturer and model
Manufacturer: KAYO; Distributor: Stomp Distribution LTD; Model: TT140
Engine
Engine: YX140, 4-Stroke, Oil Cooled; Valves: SOHC, 2 valve; Engine Displacement: 140cc; Compression Ratio: 9.8:1
Ignition and starting
Ignition System: CDI; Starting System: Kick start
Frame
Frame Design: Cradle frame; Rear Subframe Design: Steel subframe
Motor and power
Max Power: 8.2 kw @ 8000 RPM; Max Torque: 10.2 Nm @ 7500 RPM
Suspension
Front Suspension: 735mm Non-Adjustable; Rear Suspension: 360mm Non-Adjustable
Wheels
Front Rim: Steel 17×1.6; Rear Rim: Steel 14×2.15; Wheel Size: 17/14
Tyres
Front Tyres: 70/100-17; Rear Tyres: 90/100-14
Brakes
Front Brake: Dual piston – Ø210 mm disc; Rear Brake: Single piston – Ø200 mm disc
Warranty
6 months, parts only
Bore x Stroke
56.0 × 57.0 mm
Fuel System
Carburettor
Clutch
Wet, 5 disc
Transmission
Manual four speed with N-1-2-3-4
Final Drive
428 chain
Footpegs
Pro
Handlebar
Steel
Exhaust
KAYO performance
Silencer
KAYO performance
Vehicle Size
1780 x 750 x 1120mm
Wheelbase
1220mm
Ground Clearance
290mm
Fuel Capacity
5.5litres
Seat Height
855mm
Dry Weight
73.0kg
Packing Size
1560 x 380 x 735mm
Measurement
Value
Seat Height
855mm
Wheelbase
1220mm
Wheel Size
17/14
Vehicle Size
1780 x 750 x 1120mm
Ground Clearance
290mm
