Kayo

KAYO TT190R

®

£1,995.00 incl. VAT

Colour
Bank transfer · Pay on collection

Technical Specification

Age
Wheel Size
17/14
Weight
81kg
Max Rider
Charging Time
Range
Motor
ZS190, 4-Stroke, Air Cooled
Battery
Ref: TT190R
Product Description

The “R” in TTR stands for “Race”.

Racing is something Kayo knows a lot about. The factory was initially inspired by the Stomp Racing Team in the early noughties. Later, utilizing Stomps engineering know-how, Kayo went on to develop their own race team, race bikes and race focused company ethos. Initially pushing the Kayo brand hard in China to completely dominate the domestic racing scene.

Kayo is now a global brand and the TTR190 is their pinnacle, out-of-the box racing bike, dedicated to serious pit bike racers.

The driving force for the TTR190 is the well proven Zhongshen 190cc, an engine which has dominated pit bike racing all over the world for many years. This race focused powertrain coupled with fully adjustable Fastace forks and DNM rear shock, provide the basis for a well-engineered package that’s guaranteed to get you the hole-shot and allow you to clear the biggest tables on the dirt.

To put the power down, the TTR190 comes with some gnarly Kenda inspired MX pattern tyres and weight has been shaved thanks to the alloy swingarm and light weight brakes. The soundtrack is provided by the race engineered, light weight stainless steel Kayo exhaust and to keep that monster engine breathing cleanly the TTR190 features a fully enclosed air box. The huge rear suspension travel is class leading on this bike, all-in-all, nothing comes close out of the crate.

Kayo is hands down the largest manufacturer of pit bikes in the world today, dwarfing Honda with massive volume and the hi tech robot welding lines to match the demand of their bikes.

The TTR190 takes advantage of the gigantic leaps Kayo has taken in the industry over the past 20 years. Precision welding, the best available component suppliers, insane attention to detail and robustness to match the Japanese manufacturers.

There is nothing else on the market that’s this well considered and that’s before you cast your eyes across the jaw dropping plastics and graphics.

Whether you are a hardened field racer ready to do battle with your friends or kitted-up ready to race professionally around the track, the TT190-R has you covered for many years to come. Just be extremely careful not to brag too much to your friends, because jealousy can be a dangerous thing!

Key Features

Engine Displacement
187.2cc
Transmission
Manual five speed with 1-N-2-3-4-5
Wheel Size
17/14
Seat Height
850mm
Dry Weight
81kg
Manufacturer and model
Manufacturer: KAYO; Distributor: Stomp Distribution LTD; Model: TT190-R
Engine
Engine: ZS190, 4-Stroke, Air Cooled; Valves: SOHC, 2 valve; Engine Displacement: 187.2cc; Compression Ratio: 11.0:1
Ignition and starting
Ignition System: CDI; Starting System: Electric, Kick
Frame
Frame Design: Cradle frame; Rear Subframe Design: Steel subframe
Motor and power
Max Power: 12kw @ 9500 RPM; Max Torque: 13Nm @ 8000 RPM
Suspension
Front Suspension: FAST ACE 730mm Adjustable; Rear Suspension: DNM 360mm Adjustable
Wheels
Front Rim: Steel 17×1.6; Rear Rim: Steel 14×2.15; Wheel Size: 17/14; Rim Lock: Front & rear
Tyres
Front Tyres: 70/100-17; Rear Tyres: 90/100-14
Brakes
Front Brake: Dual piston – Ø210 mm disc; Rear Brake: Single piston – Ø200 mm disc
Warranty
6 months, parts only
Bore x Stroke
62.0 x 62.0mm
Clutch
Wet, 5 disc
Fuel System
Carburettor
Transmission
Manual five speed with 1-N-2-3-4-5
Final Drive
428 chain
Swing Arm
Alloy 410mm
Footpegs
Pro
Handlebar
Steel
Exhaust
KAYO performance
Silencer
KAYO performance
Vehicle Size
1765 x 1100 x 1220mm
Wheelbase
1220mm
Ground Clearance
280mm
Seat Height
850mm
Dry Weight
81kg
Additional specifications
Fuel Capacity: 5.5 litres; Packing Size: 1560 x 380 x 735mm
Measurement
Value
Seat Height
850mm
Wheelbase
1220mm
Wheel Size
17/14
Vehicle Size
1765 x 1100 x 1220mm
Ground Clearance
280mm
Contact us by appointment if you need help checking suitability and fit.
