Kayo

KAYO TT190

®

£1,599.00 incl. VAT

Colour
Bank transfer · Pay on collection

Technical Specification

Age
Wheel Size
17/14
Weight
81kg
Max Rider
Charging Time
Range
Motor
ZS190, 4-Stroke, Air Cooled
Battery
Ref: TT190
Product Description

The driving force behind the TT190 is the well-proven Zhongshen 190cc, an engine that has dominated pit bike racing all over the world for many years. This race-focused powertrain, paired with Kayo’s highly capable chassis, creates a well-engineered machine designed to dominate the competition and guarantee the hole-shot when tearing up the dirt with your mates.

To put the power down, the TT190 comes with some gnarly Kenda-inspired MX-pattern tyres. The soundtrack is provided by the race-engineered, lightweight stainless steel Kayo exhaust, and to keep that monster engine breathing cleanly, the TT190 features a fully enclosed airbox. The huge rear suspension travel is class-leading on this bike—all in all, nothing comes close to this entry-level fire-breathing monster.

Kayo stands as the world’s largest pit bike manufacturer, outproducing Honda with cutting-edge robotic welding lines that keep up with massive global demand.

The TT190 takes advantage of the gigantic leaps Kayo has made in the industry over the past 20 years—precision welding, the best available component suppliers, insane attention to detail, and robustness to match the Japanese manufacturers.

Nothing else on the market is this meticulously designed—and that’s before you even take in the striking plastics and graphics that set the TT190 apart as something truly special.

Key Features

Engine Displacement
187.2cc
Transmission
Manual five speed with 1-N-2-3-4-5
Wheel Size
17/14
Seat Height
855mm
Dry Weight
81kg
Manufacturer and model
Manufacturer: KAYO; Distributor: Stomp Distribution LTD; Model: TT190
Engine
Engine: ZS190, 4-Stroke, Air Cooled; Valves: SOHC, 2 valve; Engine Displacement: 187.2cc; Compression Ratio: 11.0:1
Ignition and starting
Ignition System: CDI; Starting System: Electric, Kick
Frame
Frame Design: Cradle frame; Rear Subframe Design: Steel subframe
Motor and power
Max Power: 12kw @ 9500 RPM; Max Torque: 13Nm @ 8000 RPM
Suspension
Front Suspension: 735mm Non-Adjustable; Rear Suspension: 360mm Non-Adjustable
Wheels
Front Rim: Steel 17×1.6; Rear Rim: Steel 14×2.15; Wheel Size: 17/14
Tyres
Front Tyres: 70/100-17; Rear Tyres: 90/100-14
Brakes
Front Brake: Dual piston – Ø210 mm disc; Rear Brake: Single piston – Ø200 mm disc
Warranty
6 months, parts only
Bore x Stroke
62.0 x 62.0mm
Fuel System
Carburettor
Clutch
Wet, 5 disc
Transmission
Manual five speed with 1-N-2-3-4-5
Final Drive
428 chain
Swing Arm
Steel 430mm
Footpegs
Pro
Handlebar
Steel
Exhaust
KAYO performance
Silencer
KAYO performance
Vehicle Size
1780 x 750 x 1220mm
Wheelbase
1220mm
Ground Clearance
290mm
Seat Height
855mm
Dry Weight
81kg
Additional specifications
Fuel Capacity: 5.5 litres; Packing Size: 1560 x 380 x 735mm
Measurement
Value
Seat Height
855mm
Wheelbase
1220mm
Wheel Size
17/14
Vehicle Size
1780 x 750 x 1220mm
Ground Clearance
290mm
Contact us by appointment if you need help checking suitability and fit.
